Mechanical Tilt Level Switch

Series m switches have an impact resistant abs shell and jacketed cable.

Mechanical tilt level switch.

Tilt level switches are used for high level indication as they are installed suspended on a cable or chain above the material being sensed. They mount horizontally and activate when tilted downward and deactivate when tilted up. The mechanical tilt level switch technology for bulk solids level measurement is the most simple reliable and economical solids level measurement technology on the market mechanical tilt level switches are suitable for multiple applications such as grains cereals animal food powders and diverse bulk solids pellets stones minerals sawdust etc. All combine electromechanical and solid state technologies for.

Often used as position indicators pump level controls and machine limit switches these switches actuate when tilted to a certain angle. Capacitive conductive diaphragm displacer float inductive optical paddle vibrating rod tilt and tuning fork models are the different types of level switches available. Differential angle is the total angle from the point of activation to the point of deactivation. Series m mechanical tilt floats are ideal for applications where the presence of mercury is a concern.

Manufacturer of level switches mechanical tilt switch mechanical diaphragm switch proximity switch and rotary paddle type offered by maschinen fabrik india private limited kolkata west bengal. Gems sensors mgre40w series m mechanical tilt float switch 5 0 out of 5 stars 1. Gems sensors 35651 buna n float large single point level switch with brass stem and mounting 1 1 4 diameter 1 8 npt male 7 8 actuation level 100va spst normally open. Level switches are sensors with an electrical contact output at a specific liquid powder or bulk level.

Varieties of mechanical switches available such as top inserted float actuated level switches top inserted displacer actuated level switch external cage float or displacer actuated level switch high temperature and pressure level switch. Mechanical tip over switches sense tilt over 360 of the vertical axis. Float displacer level switch series 700. Series m switches have an impact resistant abs shell and jacketed cable.

As the material height increases and comes in contact with the probe the material pushes the probe to the side and tilts it. Series m mechanical tilt level sensor is designed for level control and alarm applications in difficult liquids such as sewage and waste water. Applications for mechanical tilt switches include level controls appliances security alarm systems toys float switches.
